تفاصيل المنتج:
اتصل
تحدث الآن
|
| تشغيل الصمام: | إعادة الضبط اليدوي، الملف اللولبي - التمثيل المباشر | مادة الجسم: | الفولاذ المقاوم للصدأ |
|---|---|---|---|
| وسائط: | الهواء|الماء | حجم الأنبوب / المنفذ: | 1/4 " |
| نوع المنفذ: | نبتف | وظيفة: | 3 طرق - 3/2 عالمي |
| إبراز: | asco solenoid valve nf8327b231,2 way asco solenoid valve,nf8327b231 asco 3 4 solenoid valve,2 way asco solenoid valve,nf8327b231 asco 3 4 solenoid valve |
||
| Attribute | Value |
|---|---|
| Valve Actuation | Manual Reset, Solenoid - Direct Acting |
| Body Material | Stainless Steel |
| Media | Air | Water |
| Pipe / Port Size | 1/4" |
| Port Type | NPTF |
| Function | 3 way - 3/2 Universal |
The ASCO Series 327, also known as 8327, is a line of 3/2-way direct-acting solenoid valves requiring zero minimum operating pressure. Its balanced poppet construction permits high flows at minimum power levels, making it ideal for power plants, refineries, and chemical processing facilities.
The valve's PTFE rider rings and graphite-filled seals reduce friction and eliminate sticking to provide exceptional service life. The 3/2-way direct-acting solenoid valves are ideal for process valve piloting applications.
| Size | Fluids | Temperature Range | Seal Materials |
|---|---|---|---|
| 5.7 mm | Air, inert gas, water, oil | -20°C to +120°C | FPM (fluoroelastomer) |
| 5.7 mm | Air, inert gas, water, oil | -40°C to +40°C | VMQ (silicone) |
| 5.7 mm | Air, inert gas, water, oil | -60°C to +60°C | (F)VMQ ((fluoro)silicone) |
| 12 mm | Air, inert gas | -25°C to +60°C | NBR (nitrile) |
| 12 mm | Air, inert gas | -10°C to +90°C | FPM (fluoroelastomer) |
| 12 mm | Air, inert gas | -50°C to +60°C | (F)VMQ ((fluoro)silicone) |
NF8327B001 | NF8327B201 | NF8327B101 | NF8327B301 | NF8327A649 | NF8327A609 | NF8327A607 | NF8327B011 | NF8327B211 | NF8327B111 | NF8327B311 | NF8327A645 | NF8327A605 | NF8327B291 | NF8327B002 | WSNF8327B002 | WSNF8327B012 | WSNF8327B112 | WSNF8327A606 | WSNF8327A608 | WSNF8327A610 | WSNF8327A646 | WSNF8327A650 | WSNF8327B001 | WSNF8327B011 | WSNF8327B111 | WSNF8327B311 | WSNF8327A607
