| أقصى تيار تصاعد: | تيار الذروة 20 كيلو أمبير (شكل موجة 8/20 ثانية) | تسرب تيار: | أقل من 1μA كحد أقصى. جهد العمل |
|---|---|---|---|
| جهد العمل: | أقصى 35 فولت DC | النطاق الترددي: | 1MHz |
| مقاومة: | لا مقاومة أدخلت إلى الحلقة | وزن: | 175 جرام. (6.2 أوقية.) |
| إبراز: | TP48-4-N-NDI MTL Safety Barrier,TP48-4-N-NDI Safety Barrier,MTL Isolated Safety Barrier,TP48-4-N-NDI Safety Barrier,MTL Isolated Safety Barrier |
||
| Attribute | Value |
|---|---|
| Maximum surge current | 20kA peak current (8/20µs waveform) |
| Leakage current | Less than 1µA at max. working voltage |
| Working voltage | 35V dc maximum |
| Bandwidth | 1MHz |
| Resistance | No resistance introduced into loop |
| Weight | 175g. (6.2oz.) |
| Model | Description | Model | Description |
|---|---|---|---|
| TP48-N | Non-certified SPD - 1/2" NPT thread | TP48-N-NDI | Certified SPD - 1/2" NPT thread |
| TP48-I | Non-certified SPD - 20mm ISO thread | TP48-I-NDI | Certified SPD - 20mm ISO thread |
| TP48-G | Non-certified SPD - G 1/2" (BSP 1/2 inch) | TP48-G-NDI | Certified SPD - G 1/2" (BSP 1/2 inch) |
| TP48-3-N | Non-certified SPD - 1/2" NPT thread | TP48-3-N-NDI | Certified SPD - 1/2" NPT thread |
| TP48-3-I | Non-certified SPD - 20mm ISO thread | TP48-3-I-NDI | Certified SPD - 20mm ISO thread |
| TP48-3-G | Non-certified SPD - G 1/2" BSP 1/2 inch | TP48-3-G-NDI | Certified SPD - 20mm ISO thread |
| TP48-4-N | Non-certified SPD - 1/2" NPT thread | TP48-4-N-NDI | Certified SPD - 1/2" NPT thread |
| TP48-4-I | Non-certified SPD - 20mm ISO thread | TP48-4-I-NDI | Certified SPD - 20mm ISO thread |
| TP48-4-G | Non-certified SPD - G 1/2" BSP 1/2 inch | TP48-4-G-NDI | Certified SPD - G 1/2" - BSP 1/2 inch |
