Endress Hauser PH/ORP Transmitter Liquisys CPM223 With Hart Communication 0.775 Kilogram

Endress Hauser PH/ORP Transmitter Liquisys CPM223 With Hart Communication 0.775 Kilogram
Endress Hauser PH/ORP Transmitter Liquisys CPM223 With Hart Communication 0.775 Kilogram
Endress Hauser PH/ORP Transmitter Liquisys CPM223 With Hart Communication 0.775 Kilogram Endress Hauser PH/ORP Transmitter Liquisys CPM223 With Hart Communication 0.775 Kilogram
Basic Information
Place of Origin: Germany/China
Brand Name: Endress+Hauser
Certification: CE
Model Number: CPM223-PR0005
Document: CPM223 253.pdf
Minimum Order Quantity: 1pc
Price: negotiable
Packaging Details: standard carton packing
Delivery Time: 12-14weeks
Payment Terms: T/T
Supply Ability: 100pcs per month
Contact Now Chat Now
Input: One-channel-transmitter Output / Communication: 0/4-20 MA, Hart, Profibus
Ingress Protection: IP54 Sensor Input; Software: PH (glass) / ORP; Basic Version
Power Supply: 230VAC Net Weight: 0.775 Kilogram
Highlight:

HART Communication pH ORP Transmitter

,

CPM223 Endress Hauser Liquisys

,

pH ORP Transmitter CPM223

Endress+Hauser pH/ORP transmitter Liquisys CPM223


Liquisys CPM223 is a standard pH/ORP transmitter for all analog and digital Memosens sensors. It improves your operational safety thanks to continuous plausibility, process and sensor checks. Select from numerous hardware and software modules, such as relays or fieldbus communication, to adapt it exactly to your measuring task. This modularity also allows you to upgrade the transmitter at any time. A simple menu and two-point calibration make configuration and operation fast and easy.

The Liquisys CPM223 transmitter works with all pH/ORP glass and ISFET sensors in non-hazardous areas, for example in these industries and their utilities:

Chemicals

Food & Beverages

Power & Energy

Water & Wastewater

Primaries & Metal


Liquisys CPM223 features the following protocols and interfaces:


0/4...20 mA

HART

PROFIBUS DP

PROFIBUS PA


  • Measuring principle

    Potentiometric

    Application

    Water, waste water, process

    Characteristic

    4-wire transmitter with a two-line display

    Design

    pH/ORP transmitter in a panel housing (96x96 mm)

    Material

    panel housing

    Dimension

    96 mm x 96 mm x 146 mm(built in depth)
    3.74x3.74x5.61 inch (built in depth)

    Temperature sensor

    Display and current output

    Ex certification

    No

    Ingress protection

    IP54

    Input

    One-channel-transmitter

    Output / communication

    0/4-20 mA, Hart, Profibus.

    Additional certifications

    CSA Gen. Purpose


      Endress Hauser PH/ORP Transmitter Liquisys CPM223 With Hart Communication 0.775 Kilogram 0
