P+F NBN30-U4-A2 Inductive Sensor PNP Output 30mm Non-Flush

P+F NBN30-U4-A2 Inductive Sensor PNP Output 30mm Non-Flush
P+F NBN30-U4-A2 Inductive Sensor PNP Output 30mm Non-Flush P+F NBN30-U4-A2 Inductive Sensor PNP Output 30mm Non-Flush P+F NBN30-U4-A2 Inductive Sensor PNP Output 30mm Non-Flush

Large Image :  P+F NBN30-U4-A2 Inductive Sensor PNP Output 30mm Non-Flush

Product Details:
Place of Origin: DE
Brand Name: P+F
Certification: CE
Model Number: NBN30-U4-A2
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiable
Packaging Details: Original packaging
Delivery Time: 1-2 weeks
Payment Terms: T/T
Supply Ability: 100pcs per month
Contact Now Chat Now

P+F NBN30-U4-A2 Inductive Sensor PNP Output 30mm Non-Flush

Description
Switching Function: Complementary Output Type: PNP
Output Polarity: DC Operating Voltage: 10 ... 30 V
Dimensions: 40 Mm*40 Mm*118 Mm(H*W*L) Mass: 225 G
Highlight:

P+F NBN30-U4-A2

,

PNP Output Type Inductive Sensor

,

P+F NBN30-U4-A2 Inductive Sensor

P+F NBN30-U4-A2 Inductive Sensor with PNP Output Type 40 mm*40 mm*118 mm Dimensions
Product Specifications
Attribute Value
Switching function Complementary
Output type PNP
Output polarity DC
Operating voltage 10 ... 30 V
Dimensions (H×W×L) 40 mm × 40 mm × 118 mm
Mass 225 g
Product Overview
  • Sensor head bidirectional and rotatable
  • 30 mm non-flush sensing
  • 4 LEDs indicator for 360° visibility
P+F NBN30-U4-A2 Inductive Sensor PNP Output 30mm Non-Flush 0
Technical Data
General Specifications
Rated operating distance 30 mm
Installation Non-flush
Assured operating distance 0 ... 24.3 mm
Reduction factors rAl: 0.33, rCu: 0.31, r304: 0.74, rBrass: 0.38
Nominal Ratings
Switching frequency 0 ... 230 Hz
Hysteresis typ. 5%
Reverse polarity protection Yes
Short-circuit protection Pulsing
Voltage drop ≤ 2 V
Mechanical Specifications
Connection type Screw terminals
Housing material PA/metal with epoxy powder coating
Degree of protection IP68 / IP69K
Tightening torque 1.8 Nm (housing)
P+F NBN30-U4-A2 Inductive Sensor PNP Output 30mm Non-Flush 1
