CUS52D-AA1AA3 Endress+Hauser Turbidity sensor CUS52D

Basic Information

Place of Origin:	CN/DE
Brand Name:	Endress+Hause
Certification:	CE
Model Number:	CUS52D-AA1AA3
Document:	CUS52D.pdf

Minimum Order Quantity:	1pc
Price:	Negotiable
Packaging Details:	Original packaging
Delivery Time:	8-12 weeks
Payment Terms:	T/T
Supply Ability:	100pcs per month

Contact Now Chat Now

Measuring Principle:

Single Beam Scattered Light

Design:

40 Mm Sensor

Dimension:

40 Mm Design, Hygienic Clamp-version 320 X 40 Mm

Ingress Protection:

IP68

Output / Communication:

Memosens

Net Weight:

1.672kg

Highlight:

Endress Hauser turbidity sensor CUS52D

CUS52D turbidity sensor with warranty

Endress Hauser CUS52D water quality sensor

CUS52D-AA1AA3 Endress+Hauser Turbidity sensor CUS52

Name: CUS52D-AA1AA3 Endress+Hauser Turbidity sensor CUS52D
Brand: SC Automation Limited
SKU: CUS52D-AA1AA3
Availability: InStock

Field of application

Turbimax CUS52D is a smart sensor with lab accuracy that allows unattended operation of all turbidity measuring points in drinking water production and many other applications with fresh, process or salt water. You can mount it directly into your pipeline, thus saving costly bypass installations and avoiding product losses. Thanks to Memosens digital technology, the Turbimax CUS52D offers maximum process and data integrity, simple operation and allows predictive maintenance.

Turbimax CUS52D measures turbidity in:

Drinking and process water:
- From inlet to outlet in water plants
- Raw water abstraction and control
- Distribution networks
- All quality control points in water production
Saline water:
- Desalination plants
- Marine applications (e.g. monitoring of exhaust gas cleaning on ships)
Wastewater treatment plants:
- Reuse of outlet water (e.g. 4th cleaning step)
Utilities in all industries:
- From inlet to outlet in water production
- Distribution networks

Specifications

Measuring principle	Single beam scattered light
Application	Turbidity measurement in: Drinking and process water Saline water Utilities of all industries
Installation	Inline Insitu, sensor with clamp, flow cell, sensor with clamp, retractables, sensor straight, immersion in open channels
Design	40 mm sensor
Dimension	40 mm design, hygienic Clamp-version 320 x 40 mm
Material	Stainless steel version: 1.4404 Plastic version: sensor head: PEEK, shaft: PPS Optical windows: sapphire O-rings: EPDM
Measuring range	0.000 to 4000 FNU
Process pressure	Stainles steel version: 0.5 to 10 bar abs (7.3 to 145 psi abs) Plastic version: 0.5 to 6 bar abs (7.3 to 87 psi abs)
Ingress protection	IP68
Output / communication	Memosens

CUS52D-AA1AA3 Endress+Hauser Turbidity sensor CUS52D 0
