Yokogawa ADV151-P50 32-Channel Digital Input Module 24V DC

Large Image : Yokogawa ADV151-P50 32-Channel Digital Input Module 24V DC

Product Details:

Place of Origin:	Japan
Brand Name:	YOKOGAWA
Certification:	CE
Model Number:	ADV151-P50

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	negotiable
Packaging Details:	standard carton packing
Delivery Time:	on request
Payment Terms:	T/T
Supply Ability:	100pcs per month

Contact Now Chat Now

Yokogawa ADV151-P50 32-Channel Digital Input Module 24V DC

Description

Manufacturers:	Yokogawa	Number Of Input Channels:	32
Rated Input Voltage:	24 V DC (sink/source)	Input ON Voltage:	18 To 26.4 V DC
Input OFF Voltage:	5.0 V DC Or Less	Input Current (at Rated Input Voltage):	4.1 MA±20 % / Channel
Maximum Allowable Input Voltage:	30.0 V DC	Weight:	0.3 Kg
Highlight:	30V YOKOGAWA Transmitter , 32 channel YOKOGAWA Transmitter , digital input module ADV151-P50

32 Channel YOKOGAWA Transmitter DIGITAL INPUT MODULE ADV151-P50

Product Specifications

Attribute	Value
Manufacturers	Yokogawa
Number of input channels	32
Rated input voltage	24 V DC (sink/source)
Input ON voltage	18 to 26.4 V DC
Input OFF voltage	5.0 V DC or less
Input current (at rated input voltage)	4.1 mA±20 % / channel
Maximum allowable input voltage	30.0 V DC
Weight	0.3 kg

Product Description

YOKOGAWA DIGITAL INPUT MODULE ADV151-P50

The Digital Input Modules receive 32-channel or 64-channel 24 V DC ON/OFF signals. The ADV151 and ADV161 can be used in dual redundant configuration.

Model	ADV151-P/ADV151-E (*1)	ADV157	ADV161
Number of input channels	32	32	64
Rated input voltage (*2)	24 V DC (sink/source)	24 V DC (sink/source)	24 V DC (sink/source)
Input ON voltage	18 to 26.4 V DC	18 to 26.4 V DC	20 to 26.4 V DC
Input OFF voltage	5.0 V DC or less	5.0 V DC or less	5.0 V DC or less
Input current (at rated input voltage)	4.1 mA±20 % / channel	4.1 mA±20 % / channel	2.5 mA±20 % / channel
Maximum allowable input voltage	30.0 V DC	30.0 V DC	30.0 V DC
Withstanding voltage	Between input signal and system: 2 kVAC, For 1 minute Between commons: 500 VAC, For 1 minute, common every 16-channel (*3)
Functions	Function for detecting ON/OFF status Function for counting the pushbutton edges	Function for detecting ON/OFF status	Function for detecting ON/OFF status Function for counting the pushbutton edges
Input response time	8 ms or less (for status input)
Minimum ON detection time	20 ms (for pushbutton input)
Maximum ON/OFF cycle	25 Hz (for pushbutton input)
Maximum current consumption	500 mA (5 V DC)	350 mA (5 V DC)	550 mA (5 V DC)
Weight	0.3 kg	0.4 kg	0.3 kg
External connection	Pressure clamp terminal, Dedicated cable (AKB331), MIL connector cable	Pressure clamp terminal	Dedicated cable (AKB337), MIL connector cable

Related Part Numbers

AED5D-00 AIP601 AIP826 AIP827-2 AIP830-101 AIP830-101-EIM-VESA AKB331-M020 ALE111-S50 ALE111-S51 ALR121-S00 AMN33 ATD5A-00 ATK4A-00 AX01C-C010-CH AX01C-C015/CH AXG080-GA000AA1AH112B-2JA11-CH AXG100-GG000BA1AH114B-NNNNNCH AXG150-CGNF2AA2AH214BNNNNN-GRH-CH-L2 AXG4A AXG4A-CNF2121JA11/CH AXG4A-CNF2141JA11-CH-L2 AXG4A-G000141JA12-CH BT200-N00 CP451-10 DO30G E7042UD
