GDB161.9E Siemens Rotary Actuator For Ball Valves 5 Nm IP54

Large Image : GDB161.9E Siemens Rotary Actuator For Ball Valves 5 Nm IP54

Product Details:

Place of Origin:	China
Brand Name:	SIEMENS
Certification:	CE
Model Number:	GDB161.9E

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	negotiable
Packaging Details:	standard carton packing
Delivery Time:	on request
Payment Terms:	T/T
Supply Ability:	100pcs per month

Contact Now Chat Now

GDB161.9E Siemens Rotary Actuator For Ball Valves 5 Nm IP54

Description

Torque:	5 Nm	Positioning Time:	150 S
Cable Length:	0.9 M	Spring Return Function:	No
Degree Of Protection:	IP54	Ambient Temperature, Operation:	-32...55 °C
Dimensions (W X H X D):	88 X 112 X 143 Mm	Mounting Position:	Upright To Horizontal
Highlight:	GDB161.9E siemens rotary actuator , IP54 siemens rotary actuator , GDB161.9E

GDB161.9E IP54 Siemens Rotary Actuators For Ball Valves

Product Specifications

Torque	5 Nm
Positioning time	150 s
Cable length	0.9 m
Spring return function	No
Degree of protection	IP54
Ambient temperature, operation	-32...55 °C
Dimensions (W x H x D)	88 x 112 x 143 mm
Mounting position	Upright to horizontal

Product Description

Siemens rotary actuators for ball valves GDB161.9E are electromotoric rotary actuators designed for open-close, three-position or modulating control in heating, ventilation and air conditioning systems.

Compatible Applications

For 2-port and 3-port control ball valves with internally threaded connections (VAI61.. and VBI61..) or externally threaded connections (VAG61.. and VBG61..), DN15 to DN25
For open/close ball valves 2-port and changeover ball valves 3-port with internally threaded connections (VAI60.. and VBI60..) or externally threaded connections (VAG60.. and VBG60..), DN15 to DN25

Technical Specifications

Nominal torque: 5 Nm
Operating voltage: GDB141.9E and GDB161.9E AC 24 V ~ / DC 24...48 V ⎓
GDB161.9E/MO: RS-485 for Modbus RTU communication
Pre-wired with 0.9 m long connection cables

Key Features

Brushless, robust DC motors ensure reliable operation regardless of load
No end position switch required, overload proof with position retention at end stop
Maintenance-free, low-noise gears
Compatible with modulating controllers (DC 0/2...10 V), open-close or three-position controllers
Recommended minimum pulse length of 500 ms for three-point control operation

Related Part Numbers

QBM81-5

VAI51.32-16

VXP459.25-6.3

VAI51.32-25

VXP459.32-16

VAI51.40-25

VAI61.25-10

VAI51.40-40

VAI61.25-16

VAI51.50-40

VAI61.32-16

VAI51.50-63

VAI61.32-25

GLA161.9Y/101

VAI61.50-63

GLA141.9Y/101

GMA131.9E

GDA161.9Y/101

GMA161.9E

GDA141.9Y/101

VAI61.40-25

GDB161.9Y/101

VAI61.40-40

GDB141.9Y/101

VAI61.50-40

GLB161.9Y/101

GQD131.9A

GLB141.9Y/101

GQD161.9A

GDB161.9E

VBI61.32-16

VAI51.15-4

VBI61.40-25

VAI51.20-6.3

VBI61.50-40

VAI51.20-10

VBI61.50-63

VAI51.25-10

ASK77.3

VAI51.25-16
