| निर्माताओं: | YOKOGAWA | I/O चैनलों की संख्या: | 32-चैनल इनपुट |
|---|---|---|---|
| सिग्नल अलगाव: | पृथक चैनल | इनपुट संपर्क रेटिंग: | 5 वी डीसी, 20 एमए या अधिक |
| पुशबटन इनपुट फ़ंक्शन: | का समर्थन किया | nपुट प्रतिक्रिया समय: | 8 एमएस (स्थिति इनपुट के लिए) |
| न्यूनतम ऑन पता लगाने का समय: | 20 एमएस (प्रश बटन इनपुट के लिए) | वज़न: | 0.4 किलोग्राम |
| प्रमुखता देना: | YOKOGAWA analog input module,DIGITAL analog input module,ADV159-P00 |
||
| Attribute | Value |
|---|---|
| Manufacturers | Yokogawa |
| Number of I/O channels | 32-channel input |
| Signal isolation | Isolated channels |
| Input contact rating | 5 V DC, 20 mA or more |
| Pushbutton input function | Supported |
| Input response time | 8 ms (for status input) |
| Minimum ON detection time | 20 ms (for pushbutton input) |
| Weight | 0.4 kg |
| Item | ADV859 | ADV159 | ADV559 |
|---|---|---|---|
| Number of I/O channels | 16-channel input, 16-channel output | 32-channel input | 32-channel output |
| Signal isolation | Isolated channels | Isolated channels | Isolated channels |
| Input signal |
Contact input: OFF signal 100 kΩ or more, ON signal 200 Ω or less Minimum current value when contact is short-circuited: 1.25 mA Voltage input: OFF signal 4.5 to 25 V DC, ON signal ±1 V DC, 200 Ω or less |
||
| Input contact rating | 5 V DC, 20 mA or more | ||
| Pushbutton input function | Not supported | Supported | - |
| Input response time | 8 ms (for status input) | 8 ms (for status input) | |
| Minimum ON detection time | - | 20 ms (for pushbutton input) | - |
| Maximum ON/OFF cycle | 25 Hz (for pushbutton input) | ||
| Output signal | Transistor contact | - | Transistor contact |
| Output contact rating | Inductive load, resistive load: 30 V DC, 100 mA (*1) | - | Inductive load, resistive load: 30 V DC, 100 mA (*1) |
| Output response time | 16 ms or less | - | 16 ms or less |
| Pulse width | 8 ms to 7200 s | 8 ms to 7200 s | |
| Pulse width resolution | 8 ms, add max. 1ms for ON/OFF delay time | 8 ms, add max. 1ms for ON/OFF delay time | |
| Maximum current consumption | 450 mA (5 V DC) | 330 mA (5 V DC) | 570 mA (5 V DC) |
| Weight | 0.3 kg | 0.4 kg | 0.3 kg |
| External connection | Dedicated cable (KS2) | ||
| Compatible card | ST2 compatible | ST3 compatible | ST4 compatible |
